Fire Alarm Panel

Get a Price/Quote

MOQ : 1 Unit

Fire Alarm Panel Specification

Alarm time
Continuous until reset/silenced

Sensor Life
Depends on detector; typically 5-10 years

Noise Level
N/A (electronic panel)

Alarm startup time
< 5 seconds

Voltage
24V DC (system circuitry)

Working Current
~150mA (alarm condition, panel only)

Alarm Density
N/A - depends on external detectors

Control Distance
Varies as per installation specifications

Suitable For
Small to medium commercial & industrial premises

Sensitivity
As per connected detector type

Sensor Cable
2-core, 1.5 sq.mm recommended

Standby Current
< 100mA (panel only)

Wireless
No (conventional wired panel)

Sensor Type
Compatible with conventional smoke & heat detectors

Power Supply
230V AC, 50Hz main supply

Alarm Light Color
Red (Panel LED indicators)

Remote Control
No

Detection Range
Dependent on detector type and environment

Number of Zones
4 (individually monitored zones)

Operation Mode
Automatic and manual panel operation

Relative Humidity
95% RH (non-condensing)

Panel Enclosure
Metal with lockable front door

Alarm Output
Internal sounder, relay output for external hooters

Compliance
IS 2189, CE certified

Zone End-of-Line Resistor
4.7k standard

Weight
Approx. 6.5 kg (without battery)

Battery Backup
Supported, 2x 12V 7Ah Sealed Lead Acid batteries (not included)

Cable Entry
Pre-punched knockouts for cable glands

Operating Temperature
0C to +50C

Output Relay Contacts
1A, 30V DC NO/NC contacts for both alarm and fault

Dimensions
~345mm x 395mm x 100mm

Display
LED/LCD Display with zone-wise status indications

Fault Indication
Zone-wise fault monitoring and LED indication

Fire Alarm Panel Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About Fire Alarm Panel

Experience transcendent safety with the hot-selling Fire Alarm Panel, meticulously engineered for cost-effective yet pivotal fire security solutions. Featuring individually monitored zones and a decorated LED/LCD display, it provides zone-wise status indications and instant fault alerts. Its automatic or manual operation, internal sounder, and versatile relay outputs offer robust protection for small to medium commercial and industrial premises. The panel's sturdy metal enclosure, enhanced by lockable security, is built for scarcity-driven demand and exceeds compliance with IS 2189 and CE certifications.

Versatile Usage and Application

The Ravel Fire Alarm Panel is tailored for a diverse range of applications, excelling in small to medium commercial and industrial spaces where fire detection is paramount. Its compatibility with both smoke and heat detectors, along with distinguished zone monitoring, ensures swift, effective alarms. This pivotal system offers decorated safety features, making it a superior and dependable choice for service providers, suppliers, and traders who require transcendent fire security across various environments.

Favorable Sales Terms and Export Markets

Benefit from our competitive sale price and exclusive offers on the Ravel 4 Zone Fire Alarm Panel. Our rates are structured for the best value, reinforcing its reputation as a cost-effective solution. Primary export markets include India with service provision extended to suppliers and traders nationwide. Shipments are managed via our main FOB port, ensuring reliable delivery and outstanding support throughout the transaction process for all commercial customers.

FAQ's of Fire Alarm Panel:

Q: How is the Fire Alarm Panel typically used in commercial settings?

A: This panel is ideal for small to medium commercial and industrial premises, providing efficient zone-wise fire detection and immediate alert capability, thus ensuring timely evacuation and safety.

Q: What are the main benefits of choosing this fire alarm panel over others?

A: The Ravel 4 Zone Panel stands out for its transcendent reliability, cost-effectiveness, compliance with IS 2189 and CE standards, and uniquely decorated zone monitoring, offering advanced protection and easy maintenance.

Q: When should the batteries in the panel be replaced?

A: As the panel supports 2x 12V 7Ah sealed lead-acid batteries (not included), batteries typically last 3-5 years, but regular checks as per manufacturer guidelines are recommended to maintain backup performance.

Q: Where can the Fire Alarm Panel be installed?

A: This panel is designed for indoor installation in commercial and industrial environments, such as offices, factories, and service spaces where robust fire monitoring is required.

Q: What is the process for connecting external hooters to the panel?

A: External hooters can be connected via the alarm output relay contacts, rated at 1A, 30V DC (NO/NC), ensuring seamless alarm activation during fire events.
